Parking Lot Lighting

Photometric Drafting - Parking Lot Lighting

The above image shows a parking lot in four stages of design. The top shows a rendered environment with trees on a greyscale background. The lower left shows a satellite view of the existing space. The lower middle shows light level calculations over the satellite image. The lower right shows the greyscale rendering without tree obstructions. A conclusion can then be drawn to determine if the chosen fixtures will provide adequate light levels prior to installation.

Photometric Drafting - Parking Lot Lighting
